Aeotec Z-Stick Gen 5

Description

Take control of Z-Wave devices from your computer.

Aeotec Z Stick Gen5 is a ZWave USB dongle. When attached to a host processor, it becomes a Z-Wave communication device, which exposes the zensys api (serialapi) through integrated USB. This device is meant primarily to allow a host processor to control up to 232 Z-Wave devices using the Z-Wave technology protocol all the while simplifying Z-Wave network installation.

The Z Stick Gen5 is easily upgradeable by the end-user such that the latest Z-Wave protocols and commands are always available. It can be upgraded in field via its USB port which also serves as a charging port for its internal battery.

Aeotec's Z Stick makes your computer the heart of your Z-Wave network that enables you to create a remote network that's capable of controlling all aspects of your Z-Wave home automation system. It includes a battery and a simple push button that makes it easy and convenient to connect any computer with the Z-Wave network. In fact, the plug-and-play device can be connected with your PC, Laptop, Mac, and even embedded computer systems like Raspberry Pi to include/exclude modules or connect to any Z-wave devices that's discoverable in your mesh.

Aeotec Z Stick is fully compatible with Linux, Mac, Windows XP, Vista and Windows 7 systems, and can be operated through softwares, like, Homeseer, Indigo, Z-Way and Domoticz. When configured with a Z-wave network, Z Stick can potentially turn your personal computer into a central controller/hub of your home automation system.

Specifications

• Power Supply: USB DC 4.75V to 5.25V;
• Built-in rechargeable lithium battery 3.7V, 100mAh.
• Max Standby Current: 30uA
• Max Operating Current: 98mA in PA mode or 40mA in normal mode
• Operating Temperature: 0 to 50.
• Storage Temperature: -20 to 70.
• Operating Distance: Up to 500 feet/150 metres outdoors in normal mode, 1310 feet/400 metres outdoors in PA mode.
