Nano Switch. Control switches and sockets wirelessly.
Convert any switch or outlet into a ZWave connected switch or outlet and control it wirelessly. Aeotec Nano Switch allows you to automate, schedule and manually control any of your home's wall switches or power outlets using Z-Wave gateways, hubs and apps.
Super Small Switch
Super small, only 42.5 x 40 x 20 mm, Nano Switch can be easily installed in the wall or wiring box behind any of your home's existing switches or sockets, requiring nothing in your home to be changed. This invisible method of installation works with a neutral wiring and allows for Nano Switch to be controlled both by Z-Wave and any existing switch. It can connect to 2 external manual switches to control the load ON/OFF independently. Its surface has a pin socket, which can be used for connecting to the touch panel, so you can also use the touch panel to control the Nano Switch.
Utilizing Z-Wave Plus and Aeotec's Gen5 technology, Nano Switch is compatible with certified Z-Wave gateways, hubs and software including Samsung SmartThings, Mios Vera, Fibaro, Jeedom, and Open Z-Wave. It'll also work with Amazon Alexa when used with an Alexa compatible hub or gateway such as SmartThings.
Works with your existing socket or switch
Aeotec Nano Switch works with any socket or switch in your home, giving you a chance not to change your home design. You don't have to change your existing switches at all.
Safely small and controllable from anywhere
Nano Switch can be easily controlled and scheduled trough the Z-Wave network by a Z-Wave gateway and app. It can also be controlled by other Z-Wave devices such as Aeotec's WallMote.
Beside its small size that allows your Nano Switch to be installed behind your home's switches or sockets, Nano Switch also features with In-built surge protection and AES-128 bit wireless encryption.
Nano Switch is a part of Aeotec's Gen5 range and is engineered upon the latest version of Z-Wave - Z-Wave Plus that features with lower power consumption and a 250% faster response time.
Safer and easier wiring
Nano Switch only works with switches and outlets that utilise a neutral wire. Thanks to its smaller design, Nano Switch also connects to wires 25% thicker than past models and can can control up to 15 amps of power.
Nano Switch allows for firmware updates to be wirelessly installed via Z-Wave Plus and supports Over The Air (OTA) feature for the products firmware upgrade.
- Frequency: 868.42 Mhz
- Model number: ZW139
- Power input: 230V 50Hz, Max: 10A
- Repeater: Yes
- Beaming: Yes
- AES 128 Security: Yes
- Max standby power: <0.8W.
- Wiring: 3 wires.
- Max load: 10A.
- Operating temperature: 0℃ to 40℃
- Relative humidity: 8% to 80%.
- Dimensions: 42.5 x 40 x 20 mm (1.7 x 1.6 x 0.8 in).
- Operating distance: Up to 150 meters outdoors.
ManualsAeotec Nano Switch User Manual (Size: 452 KB)
Aeotec Nano Switch Engineering Sheet (Size: 322 KB)
